Our Automatic Capping Machine is a precision-engineered solution designed to efficiently and consistently apply caps to bottles and containers across various industries, including food and beverage, pharmaceuticals, and cosmetics. These machines enhance productivity and ensure a secure seal, minimizing the risk of contamination or leakage. The machine operates by automatically picking and placing caps onto containers, securely tightening them to create a tight seal. The process is highly automated, minimizing manual intervention and reducing the risk of errors and inconsistencies. Equipped with a cap feeding system that supplies caps to the capping head or station, it uses mechanisms such as vibratory bowls, centrifugal feeders, or mechanical pick-and-place systems to ensure a steady supply of caps. The capping heads are the components responsible for placing caps onto containers and applying the necessary torque to tighten them securely. Depending on the type of caps used, capping heads may use different mechanisms such as chuck cappers, spindle cappers, or snap cappers. Designed to accommodate a wide range of container shapes, sizes, and cap types, they feature adjustable settings to control parameters such as cap torque, capping speed, and container height, allowing for flexibility in production.
Capacity
30 - 80 BPM
Automation
Fully Automatic
Voltage
220 - 230 V
Material
Stainless Steel
Tightens screw-on caps with adjustable torque settings. Ideal for plastic and metal screw caps.
Applies aluminum closures that are rolled onto the bottle neck, providing a tamper-evident seal. Commonly used for beverages and pharmaceuticals.
For plastic caps that simply snap onto the container. Used in various industries for ease of use.
Uses rotating spindles to tighten caps. Each spindle is spring-loaded and driven by a torque-sensitive individual motor for increased contact and reduced wear.
| Parameter | Specification |
|---|---|
| Machine Type | Automatic Screw Capping Machine |
| Production Capacity | 30 - 80 Bottles Per Minute |
| Container Type | Bottles and Jars |
| Material | Stainless Steel (Food Grade) |
| Voltage | 220 - 230 V, Single Phase |
| Power Consumption | 0.75 kW |
| Cap Size Range | 32 - 50 mm |
| Number of Heads | Single Head (Multi-head Optional) |
| Country of Origin | Made in India |
| Automation Grade | Fully Automatic |
Contact our team today for a custom quote and technical consultation for your automatic capping machine requirements in Delhi NCR.
