High-speed automatic roll-fed BOPP labeling machines for precise wrap-around label application on cylindrical containers. Using hot melt glue technology, these machines are ideal for the beverage, food, pharmaceutical, and personal care industries. Constructed from stainless steel and featuring advanced PLC controls with servo-driven label cutting and application for accuracy and efficiency.
Price
₹ 700,000.00
0% GST (Exports) + 18% (Domestic)
MOQ
1 Unit/Units
In Stock / Made to Order
Bottles are fed onto the conveyor and separated using a star wheel or infeed screw. This ensures consistent spacing and orientation for accurate labeling.
The BOPP label roll is fed into the machine, where a rotating blade precisely cuts the label to length. Hot melt glue is then applied to one edge of the cut label.
The cut and glued label is transferred onto a vacuum drum. As the bottle passes the labeling station, the label is wrapped around the container by a synchronized belt or rollers.
The labeled bottle is discharged from the machine onto the next stage of the production line. Sensors and alarms automatically detect missing labels or jams to ensure quality.
| Parameter | Hi-Fill Standard Rating |
|---|---|
| Machine Type | Automatic Roll-Fed Hot Melt Glue Labeling |
| Labeling Speed | 60 - 120 Bottles Per Minute (Customizable) |
| Bottle Type | Round / Cylindrical (Plastic, Glass, Metal) |
| Bottle Size Range | Diameter 40-120mm, Height 30-200mm |
| Label Material | BOPP / OPP / Pearl Film / Composite Paper |
| Label Size Range | Height 10-180mm, Length 20-320mm |
| Construction Material | Stainless Steel 304 / Aluminum Alloy |
| Control System | PLC with HMI Touch Screen & Servo Motors |
| Power Requirements | 3-Phase, 415V, 50Hz, ~8-9kW |
| Key Features | Hot Melt Glue Application, Vacuum Drum, Auto Splicing, Precision Cutting, Fast Changeover |
Submit your BOPP labeling machine specifications directly to Hi-Fill Engineers & Fabricators in New Delhi. Our industrial design team will prepare a technical quotation within 24 hours.
